SuperMap学习系列（四）—鼠标移动（高亮显示）

2016/7/21 14:54:53 0人评论 4066 次

SuperMap学习系列（四）—鼠标移动（高亮显示）
学习笔记，方便以后查阅。参考超图技术资源中心--代码库：
http://support.supermap.com.cn/ProductCenter/ResourceCenter/CodeLibrary.aspx

[html]view plaincopy

			<p><!DOCTYPE html>

			<html xmlns="<a target="_blank" href="http://www.w3.org/1999/xhtml">http://www.w3.org/1999/xhtml</a>">

			<head>

			    <meta http-equiv="Content-Type" content="text/html; charset=utf-8" />

			    <title></title>

			    <script src="libs/SuperMap.Include.js"></script>

			    <script type="text/javascript">

			        var style = {

			            strokeColor: "#304DBE",

			            strokeOpacity: 0,

			            fillColor: "#00ff00",

			            fillOpacity: 0,

			        };

			        var selectStyle = {

			            fillColor: "#ffcc33",

			            strokeColor: "#ccff99",

			            strokeWidth: 2,

			            graphZIndex: 1

			        };

			        var map, layer, vectorLayer, selectFeature;

			        // 设置访问的GIS服务地址

			        var url = "<a target="_blank" href="http://localhost:8090/iserver/services/map-ChinaTestWorkPlace/rest/maps/ChinaTest">http://localhost:8090/iserver/services/map-ChinaTestWorkPlace/rest/maps/ChinaTest</a>";

			        function GetMap() {

			            // 创建地图对象

			            map = new SuperMap.Map("map");

			            //control = new SuperMap.Control.MousePosition();     //该控件显示鼠标移动时，所在点的地理坐标。

			            //map.addControl(control);  //添加控件

			            // 创建图层对象

			            layer = new SuperMap.Layer.TiledDynamicRESTLayer("World", url, { transparent: true, cacheEnabled: true }, { maxResolution: "auto" });

			            layer.events.on({ "layerInitialized": addLayer });

			            vectorLayer = new SuperMap.Layer.Vector("Vector Layer");</p><p>            selectFeature = new SuperMap.Control.SelectFeature(vectorLayer, {

			                onSelect: onFeatureSelect,

			                onUnselect: onUnFeatureSelect,

			                hover: true

			            });

			            map.addControl(selectFeature);

			            selectFeature.activate();

			        }

			        // 加载图层

			        function addLayer() {

			            // 向Map添加图层

			            map.addLayers([layer, vectorLayer]);

			            map.setCenter(new SuperMap.LonLat(116.409749, 39.912344), 1);

			            QueryBySQL();

			        }

			        //查询函数

			        function QueryBySQL() {

			            var queryParam, queryBySQLParams, queryBySQLService;

			            //SuperMap.REST.FilterParameter 查询过滤条件参数类。 该类用于设置查询数据集的查询过滤参数。

			            queryParam = new SuperMap.REST.FilterParameter({

			                name: "<a target="_blank" href="mailto:Provinces_R@China400">Provinces_R@China400</a>"   //ChinaTest地图中的图层名称

			            });

			            //SuperMap.REST.QueryBySQLParameters SQL 查询参数类。 该类用于设置 SQL 查询的相关参数。

			            queryBySQLParams = new SuperMap.REST.QueryBySQLParameters({

			                queryParams: [queryParam]

			            });

			            //SuperMap.REST.QueryBySQLService SQL 查询服务类。 在一个或多个指定的图层上查询符合 SQL 条件的空间地物信息。

			            queryBySQLService = new SuperMap.REST.QueryBySQLService(url, {

			                eventListeners: { "processCompleted": processCompleted, "processFailed": processFailed }

			            });

			            queryBySQLService.processAsync(queryBySQLParams);

			        }

			        //查询成功

			        function processCompleted(queryEventArgs) {

			            var i, j, feature,

			                    result = queryEventArgs.result;

			            if (result && result.recordsets) {

			                for (i = 0; i < result.recordsets.length; i++) {

			                    if (result.recordsets[i].features) {

			                        for (j = 0; j < result.recordsets[i].features.length; j++) {

			                            feature = result.recordsets[i].features[j];

			                            feature.style = style;

			                            vectorLayer.addFeatures(feature);

			                        }

			                    }

			                }

			            }

			        }

			        function processFailed(e) {

			            alert(e.error.errorMsg);

			        }

			        function onUnFeatureSelect(feature) {

			            feature.style = style;

			            vectorLayer.redraw();

			        }

			        function onFeatureSelect(feature) {

			            feature.style = selectStyle;

			            vectorLayer.redraw();

			        }

			    </script>

			</head>

			<body onload="GetMap()">

			    <div id="map" style="height: 640px; width: 720px; border: 1px solid red; margin-left: auto; margin-right: auto;"></div>

			</body>

			</html>

			</p>
